Launch X431 Creader 3001 Engine Full Obd2 Code Reader Diagnostic Tool OBDII CR3001 Scanner Turn Off Engine Free Update

Place of Origin	CHINA
Brand Name	JIUTECH-Lucy
Model Number	for LAUNCH X431 Creader 3001
Minimum Order Quantity	1
Packaging Details	PACKAGE
Delivery Time	1 work day
Payment Terms	T/T, Western Union, MoneyGram
Supply Ability	1000

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details

Model Name	For LAUNCH X431 Creader 3001	Origin	Mainland China
Quality	Superior	Shipping Terms	DHL,EMS,TNT,UPS,FEDEX
Software Version	2024 Version	Creader 3001 Function 5	Turns Off Malfunction Indicator Light(MIL)
Creader 3001 Place Of Origin	Shenzhen, China	Item Name	Launch Creader 3001
Creader 3001 Function 2	Read Live Data	Creader 3001 Function 1	Read & Clear DTCs
Creader 3001 Function 4	Views Freeze Frame Data	Creader 3001 Function 3	Identify VIN Information
Highlight	OBDII CR3001 scanner , Full obd2 code reader Diagnostic Tool , Launch X431 Creader 3001 Diagnostic Tool

Leave a Message

Product Description

LAUNCH full OBDII/EOBD code reader scanner Creader 3001 diagnostic tool

Product Introduction:

CReader 3001 provides full OBDII/EOBD diagnostic functions and meets protocols such as ISO9141-2, ISO14230-4, SAEJ1850, and ISO15765-4

Support Full 10 Engine System Functions

Reading Codes:Show the detailed description of the Diagnostic Trouble Code (DTCs)

Erasing Codes & Reset:Turns off Check Engine Light (MIL), clears codes and resets monitors.

Data Stream:Reads and displays live ECU/PCM data stream, plotting functions graphically and stores freeze frame data.

I/M Readiness Status:Shows whether the various emissions-related systems on the vehicle are operating properly and are ready for inspection and maintenance testing.

Read Live Data Stream:Show the information of continuous data stream from a vehicle in live graphic (waveform) display.

View Freeze Frame Data:Check the certain vehicle conditions which are recorded by the on-board computer at the time the emission-related fault occurs.

O2 Sensor Test:Allows retrieval and viewing of O2 sensor monitor test results for the most recently performed tests from the vehicle’s on-board computer.

On-Board Monitor Test:Retrieves and displays test results for emission-related powertrain components and systems.

Read Vehicle Information:Display the information such as VIN (Vehicle Identification Number), CID (Calibration ID) and CVN (Calibration verification number), etc.

Component Test:Certain vehicle components can be actuated by commands sent from the scanner to test their operability

Support OBD 2 protocols car : (must be OBD2 porotocols car )

1.SAE J1850 PWM(41.6Kbaud)

2.SAE J1850 VPW(10.4Kbaud)

3.ISO9141-2(5 baud init,10.4Kbaud)

4.ISO14230-4 KWP(5 baud init,10.4 Kbaud)

5.ISO14230-4 KWP(fast init,10.4 Kbaud)

6.ISO15765-4 CAN(11bit ID,500 Kbaud)

7.ISO15765-4 CAN(29bit ID,500 Kbaud)

8.ISO15765-4 CAN(11bit ID,250 Kbaud)

9.ISO15765-4 CAN(29bit ID,250 Kbaud)

Multi-Language:English , French , Russian , Spanish ,German, Italian ,Portuguese

Specifications:

Screen: 1.77"TFT, 160*128dpi

Voltage Range: 9-18V

Operating Temperature :0℃-50℃(32℉-122℉)

Environment Temperature:-20℃-70℃(-4℉-158℉)

Dimension :118mm*68mm*22.3mm(4.65"*2.68"*0.88")

Weight: <200g

Support car models for OBDII diagnostic function:

American Car :

Need Standard OBD2 Cars from 2000 to now

for Chrysler , for Ford, for GM, For Jeep ...

European Car :

Need Standard OBD2 Cars from 2003 to now

For Alfa romeo , for SAAB ,for Acura , for Opel , for Audi for Seat , for Peugeot , for Renault

For Bentley , for Skoda , for Daewoo , for Benz , for Land Rover , for BMW , for Vauxhall , for Citroen , for Volvo , for Fiat , for VW , for Ford , for Jaguar...

Japanese Car:

Need Standard OBD2 Cars from 2006 to now

for KIA, for Isuzu, for Honda , for Mitsubishi, for Hyundai , for Dacia , for Lexus , for Mazda, for Nissan, for Subaru , for Suzuki, for Toyota...

Chinese Car:

Need Standard OBD2 Cars from 2009 to now

NOTE:Even though it compatible with most cars, but different regions support the vehicle OBD2 protocol at different times, or some car is spercial design, so it may not compatible with some cars which do not support OBD2 protocol
